Cleveland® C33611 HG-4LL General Purpose Non-Center Cutting Single End Square End End Mill, 1/4 in Dia Cutter, 5/8 in Length of Cut, 4 Flutes, 3/8 in Dia Shank, 2-7/16 in OAL, TiN Coated
Cleveland® C33611 HG-4LL General Purpose Non-Center Cutting Single End Square End End Mill, 1/4 in Dia Cutter, 5/8 in Length of Cut, 4 Flutes, 3/8 in Dia Shank, 2-7/16 in OAL, TiN Coated
Manufacturer: Greenfield Industries
Brand: Cleveland®
Part #: CTD-C33611
MPN: C33611
CPN:
| Cutter Diameter | : | 1/4 in |
| Cutting Direction | : | Left Hand |
| Finish | : | TiN Coated |
| Flute Type | : | Spiral |
| Helix Angle | : | 30 deg |
| Length of Cut | : | 5/8 in |
| Material | : | HSS |
| Number of Flutes | : | 4 |
| Overall Length | : | 2-7/16 in |
| Series | : | HG-4LL |
| Shank Diameter | : | 3/8 in |
| Shank Type | : | Straight/Weldon Flat |
| Type | : | General Purpose Non-Center Cutting Single End Square End |
Cleveland® End Mill, General Purpose Non-Center Cutting Single End Square End, Series: HG-4LL, 1/4 in Diameter Cutter, 2-7/16 in Overall Length, 5/8 in Length of Cut, 4 Flutes, Spiral Flute, 3/8 in Shank Diameter, Left Hand Cutting Direction, 30 deg Helix Angle, Straight/Weldon Flat Shank, HSS, TiN Coated
- 32 deg left hand helix for reverse spindle operation
- 4-Flute design delivers smoother finish
- Multi-flute end mills are better for peripheral cuts
- Multi-flute end mills have a heavy duty cross section for better rigidity
- Increased number of flutes mean more cutting edges, providing more cutting action
- Coatings reduce heat and abrasion to increase tool life
- The increased lubricity of the coating surface reduces material adhesion and built-up edge, enabling even higher feed rates
- Coatings reduce the amount of torque required for machining to allow more efficient use of equipment
- TiN (titanium nitride) coating in gold color intended for aggressive machining
- TiN coating increase machining speed 25 to 30% versus bright speeds
- Applicable on alloy steel, copper alloys, cast iron and magnesium
