SGS® 51810 Ice-Carb 140 Internal Coolant High Performance Drill, 15/64 in Drill - Fraction, 0.2344 in Drill - Decimal Inch, 95 mm OAL, Micro Grain Solid Carbide, AlTiN Coated
SGS® 51810 Ice-Carb 140 Internal Coolant High Performance Drill, 15/64 in Drill - Fraction, 0.2344 in Drill - Decimal Inch, 95 mm OAL, Micro Grain Solid Carbide, AlTiN Coated
Manufacturer: KYOCERA SGS Precision tools, Inc.
Brand: SGS®
Part #: SGS-51810
MPN: 51810
CPN:
| Applicable Materials | : | Cast Iron, Steel, Stainless Steel and Titanium |
| Cutting Depth | : | 8XD |
| Cutting Direction | : | Right Hand |
| Cutting Edge Material | : | Micro Grain Solid Carbide |
| Drill Size - Decimal Inch | : | 0.2344 in |
| Drill Size - Fraction | : | 15/64 in |
| Finish | : | AlTiN Coated |
| Flute Length | : | 57 mm |
| Flute Type | : | Spiral |
| Material | : | Micro Grain Solid Carbide |
| Number of Flutes | : | 2 |
| Overall Length | : | 95 mm |
| Point Angle | : | 140 deg |
| Point Type | : | Self-Centering |
| Series | : | Ice-Carb 140 |
| Shank Size | : | 6 mm |
| Shank Type | : | Common Normal |
| Type | : | Internal Coolant |
SGS® High Performance Drill, Internal Coolant, Series: Ice-Carb 140, 15/64 in Drill - Fraction, 0.2344 in Drill - Decimal Inch, 95 mm Overall Length, 8XD Cutting Depth, 2 Flutes, Spiral Flute, 57 mm Flute Length, 6 mm Shank, Common Normal Shank, 140 deg Point, Self-Centering Point, Right Hand Cutting Direction, Micro Grain Solid Carbide Cutting Edge, Micro Grain Solid Carbide, AlTiN Coated, Applicable Materials: Cast Iron, Steel, Stainless Steel and Titanium
- Coolant through design
- High penetration 140 deg point geometry
- Engineered cutting edges
